Switching Action | SPST |
---|---|
Insertion | Horizontal |
Application | High or Low Limit |
Operating Temperature Range | 100 to 240°F (38 to 116°C) |
Approvals | UL-recognized, AGA, and CSA-certified |
Differential Temperature | Fixed |
Sensing Bulb Material | Copper |
Sensing Bulb Size | 3/8" x 2-7/8" |
Capillary Bulb Pressure Rating | 200 psi (1379 kPa) |
Wiring | Screw terminals |
