Reed 312FC Thermometer Surface -20 To 120C & 0 To 250F

Reed 312FC Thermometer Surface -20 To 120C & 0 To 250F
Images for general purposes only. Actual may be different than depicted.
Reed 312FC Thermometer Surface -20 To 120C & 0 To 250F

Reed 312FC Thermometer Surface -20 To 120C & 0 To 250F

SKU: 312FC
Out of Stock
Rating:
$64.96 /ea
0
$0.00
0
$0.00
0
  • Dual magnet mount surface thermometers specifically designed to be used on horizontal or ferrous non-horizontal surfaces
  • Reaches sensing equilibrium (stability) within three minutes
  • Features two alnico magnets that act as the thermometerÕs base and hold it in place on ferrous surfaces
  • Bimetallic sensor is a specially processed alloy that is preconditioned and pretested for permanent calibration and maximum stability
  • Sensor is located in a draft shield and is in virtual thermal contact with the surface to be measured
  • Relatively quick response time
  • Designed for applications such as: hot plates; griddles; die-cast dies; foundry core boxes; annealing ovens; weld preheats; motors; generators, engines; bearings; boilers, tanks, and drums

    Specifications:
    Functional Specifications
    Accuracy: ±2% of full scale
    Time Constant: From 0.06 to 1 min. (depending on range)

    General Specifications
    Dimensions: 2" dia. x 1/2 h. (5.1 x 1.3 cm)
    Weight: 1 1/2 oz. (43 g)
