| Supply Voltage | 9.8 VDC to 16.5 VDC; 15 VDC nominal (from SA bus) |
|---|---|
| Terminations | Modular jack and screw terminal block |
| Modular jack and screw terminal block | 32 to 104°F (0 to 40°C) |
| Temperature Sensor Type | Digital temperature sensor |
| Ambient Operating Temperature | 32°F to 122°F (0°C to 50°C); 10% to 90% RH, noncondensing; 85°F (29°C) maximum dew point |
| Temperature Accuracy | ±0.36°F (±0.2°C) at 70°F (21°C) |
| Network Sensor Addressing | DIP switch set from 199 to 206; factory set at 199 |
| Communication Rate | Auto-detect: 9.6 kbps, 19.2 kbps, 38.4 kbps, or 76.8 kbps |
| Base Current Draw | 3 mA maximum (non-transmitting) |
| Approvals | UL-listed, FCC compliant, CE mark, RoHS2, RCM mark, and CSA-certified |
