| Electrical Connections | 3-position and 2-position screw terminal blocks |
|---|---|
| Acceptable Wire Gauge | 16 AWG to 24 AWG wire; 18 AWG wire preferred |
| Power Requirements | 12 VDC to 30 VDC or 18 VAC to 30 VAC at 50/60 Hz, Class 2 |
| Material | Blue plastic cover with blue plastic housing and probe |
| RH Accuracy | ±3% |
| Probe Length | 6.25" |
| Enclosure Type | Duct Probe |
| Temperature Range | -20 to 140°F |
| Temperature Sensor Type | Thin film nickel 1K ohm at 70°F (21°C) |
| Approvals | CE, IEC, and UL approvals |
